IKO
SKU: na49/32-iko
Availability: In Stock ✅
BULK PRICING: Click Here to Enquire
The NA49/32 is a Standard Duty Open Type, Single Row Machined Needle Roller Bearing with an Inner Ring. The Inner Ring is separable from the Cage and Outer Ring, while the Outer Ring is fixed to the Cage and has an oil groove and an oil hole. Bearings with an Inner Ring are used when the shaft being used isn't heat-treated and finished by grinding. In caged Needle Roller Bearings like this one, the Needles are precisely guided by the Cage to achieve ideal load distribution. These Bearings are designed for high load carrying capacity in radially compact arrangements and are used in most general purpose applications. The Bearing's dimensions are 32X52X20mm.
The INA equivalent is NA49/32-XL.
| NA | 49 | /32 | |
|---|---|---|---|
| Single Row Caged Needle Roller Bearing | Dimension Series 49 | 32mm - Bore Size | Including Inner Ring |
32
52
20
40
31.2
47.8
NA49/32-XL
10000
120°C/248°F
-20°C/-4°F
DescriptionThe NA49/32 is a Standard Duty Open Type, Single Row Machined Needle Roller Bearing with an Inner Ring. The Inner Ring is separable from the Cage and Outer Ring, while the Outer Ring is fixed to the Cage and has an oil groove and an oil hole. Bearings with an Inner Ring are used when the shaft being used isn't heat-treated and finished by grinding. In caged Needle Roller Bearings like this one, the Needles are precisely guided by the Cage to achieve ideal load distribution. These Bearings are designed for high load carrying capacity in radially compact arrangements and are used in most general purpose applications. The Bearing's dimensions are 32X52X20mm. The INA equivalent is NA49/32-XL.
Product InformationBRAND: SKU:na49/32-iko AVAILABILITY:In Stock ✅ WEIGHT:0.165 kg Technical DataInside Diameter (mm):32 Outside Diameter (mm):52 Width (mm):20 Nominal Roller Set Bore Diameter (mm):40 Dynamic Load Rating (kN):31.2 Static Load Rating (kN):47.8 INA Equivalent:NA49/32-XL Allowable Rotational Speed (r/min):10000 Max. Operating Temperature:120°C/248°F Min. Operating Temperature:-20°C/-4°F | ||||||||
