NA69/32-ZW-XL INA Machined Needle Roller Bearing - 32X52X36MM

Name: NA69/32-ZW-XL INA Machined Needle Roller Bearing - 32X52X36MM
Brand: INA
SKU: na69/32-zw-xl-ina
Availability: InStock

SKU: na69/32-zw-xl-ina

Availability: In Stock ✅

BULK PRICING: Click Here to Enquire

C$179.33

Description

The NA69/32-ZW-XL is a Standard Duty Open Type, Double Row Machined Needle Roller Bearing with an Inner Ring. The Inner Ring is separable from the Cage and Outer Ring, while the Outer Ring is fixed to the Cage and has a lubrication groove and an oil hole. Bearings with an Inner Ring are used when the shaft being used isn't heat-treated and finished by grinding. In caged Needle Roller Bearings like this one, the Needles are precisely guided by the Cage to achieve ideal load distribution. These Bearings are designed for high radial load carrying capacity in radially compact arrangements and are used in most general purpose applications. The Bearing's dimensions are 32X52X36mm.

The IKO equivalent is NA69/32.

NA	69	/32	ZW	XL
Caged Needle Roller Bearing	Dimension Series 69	32mm - Bore Size	Double Row Bearing	X-Life Bearing	Including Inner Ring

Product Information

BRAND:

SKU:na69/32-zw-xl-ina

AVAILABILITY:In Stock ✅

WEIGHT:0.289 kg

Technical Data

Inside Diameter (mm):

Outside Diameter (mm):

Width (mm):

Raceway Diameter Inner Ring (mm):

Fatigue Load Rating (kN):

15.4

IKO Equivalent:

NA69/32

Dynamic Load Rating (kN):

Limiting Speed Rating (r/min):

11100

Reference Speed Rating (r/min):

6100

Static Load Rating (kN):

Max. Operating Temperature:

120°C/248Â°F

Min. Operating Temperature:

-30°C/-22Â°F

Description

The IKO equivalent is NA69/32.

NA	69	/32	ZW	XL
Caged Needle Roller Bearing	Dimension Series 69	32mm - Bore Size	Double Row Bearing	X-Life Bearing	Including Inner Ring

Product Information

BRAND:

SKU:na69/32-zw-xl-ina

AVAILABILITY:In Stock ✅

WEIGHT:0.289 kg

Technical Data

Inside Diameter (mm):

Outside Diameter (mm):

Width (mm):

Raceway Diameter Inner Ring (mm):

Fatigue Load Rating (kN):

15.4

IKO Equivalent:

NA69/32

Dynamic Load Rating (kN):

Limiting Speed Rating (r/min):

11100

Reference Speed Rating (r/min):

6100

Static Load Rating (kN):

Max. Operating Temperature:

120°C/248Â°F

Min. Operating Temperature:

-30°C/-22Â°F
