INA
SKU: nki5/12-tv-xl-ina
Availability: In Stock ✅
BULK PRICING: Click Here to Enquire
The NKI5/12-TV-XL is a Light Duty Open Type, Single Row Machined Needle Roller Bearing with an Inner Ring. The Inner Ring is separable from the Cage and Outer Ring, while the Outer Ring is fixed to the Cage. Bearings with an Inner Ring are used when the shaft being used isn't heat-treated and finished by grinding. In caged Needle Roller Bearings like this one, the Needles are precisely guided by the Cage to achieve ideal load distribution. These Bearings are designed for high load carrying capacity in radially compact arrangements and are used in most general purpose applications. The Bearing's dimensions are 5x15x12mm.
The IKO equivalent is TAFI51512.
| NKI | 5 | /12 | TV | XL | |
|---|---|---|---|---|---|
| Single Row Caged Needle Roller Bearing | 5mm Bore Size | 12mm Width | Cage Made from Glass Fibre Reinforced Polyamide | X-Life Bearing | Including Inner Ring |
5
15
12
8
Glass Fibre Reinforced Polyamide
4.45
4.1
0.7
TAFI51512
32500
32500
120°C/248°F
-20°C/-4°F
DescriptionThe NKI5/12-TV-XL is a Light Duty Open Type, Single Row Machined Needle Roller Bearing with an Inner Ring. The Inner Ring is separable from the Cage and Outer Ring, while the Outer Ring is fixed to the Cage. Bearings with an Inner Ring are used when the shaft being used isn't heat-treated and finished by grinding. In caged Needle Roller Bearings like this one, the Needles are precisely guided by the Cage to achieve ideal load distribution. These Bearings are designed for high load carrying capacity in radially compact arrangements and are used in most general purpose applications. The Bearing's dimensions are 5x15x12mm. The IKO equivalent is TAFI51512.
Product InformationBRAND: SKU:nki5/12-tv-xl-ina AVAILABILITY:In Stock ✅ WEIGHT:0.012 kg Technical DataInside Diameter (mm):5 Outside Diameter (mm):15 Width (mm):12 Raceway Diameter Inner Ring (mm):8 Cage Type:Glass Fibre Reinforced Polyamide Dynamic Load Rating (kN):4.45 Static Load Rating (kN):4.1 Fatigue Load Rating (kN):0.7 IKO Equivalent:TAFI51512 Limiting Speed Rating (r/min):32500 Reference Speed Rating (r/min):32500 Max. Operating Temperature:120°C/248°F Min. Operating Temperature:-20°C/-4°F | ||||||||||||
