NNF5011ADB-2LSV - SKF Double Row Cylindrical Roller - 55x90x46mm

Engineered with precision and quality craftsmanship, the NNF5011ADB-2LSV SKF is designed to ensure maximum performance of your machinery. This double row, full complement bearing has a two-piece inner ring held together by a retaining ring. The inner ring has three integral flanges, and the outer ring has one central integral flange. It has two PUR contact seals, and the outer ring has two snap ring grooves. The dimensions of the SKF NNF5011ADB-2LSV SKF bearing are 55x90x46mm.

Key Features

Cylindrical Roller Design

The NNF5011ADB-2LSV SKF bearing features a cylindrical roller design, optimising load distribution and facilitating high radial load capacity. NNF-type has a two-piece inner ring held together by a retaining ring. The inner ring has three integral flanges, and the outer ring has one central integral flange. Therefore, this type is used to axially locate a shaft in both directions.

Sealed for Protection

The NNF5011ADB-2LSV SKF bearing has a PUR contact seal on both sides which are fitted in a recess on the inner ring shoulder. The seals retain the lubrication in the bearing while excluding contaminants.

High-Speed Capability

The NNF5011 ADB-2LSV SKF bearing is designed to handle high-speed operations while maintaining low noise and vibration levels. This ensures smooth and efficient rotation in dynamic environments without compromising stability. This makes it ideal for applications that demand rapid rotation.

Annular Lubrication Groove and Holes

Equipped with an annular groove and three lubrication holes for lubricant distribution, the NNF5011ADB-2LSV SKF bearing makes lubrication an easy process reducing maintenance time and intervals.
