IKO
RNA4830 IKO Machined Needle Roller Bearing - 165X190X40MM
SKU: rna4830-iko
Availability: In Stock ✅
BULK PRICING: Click Here to Enquire
Description
The RNA4830 is a Standard Duty Open Type, Single Row Machined Needle Roller Bearing with an oil groove and oil hole in the Outer Ring. This Bearing has no Inner Ring, meaning the Needle Rollers are mounted directly onto the shaft. As such, the Bearing has better running accuracy as it isn't affected by assembling an Inner Ring with the shaft. In caged Needle Roller Bearings like this one, the Needles are precisely guided by the Cage to achieve ideal load distribution. These Bearings are designed for high load carrying capacity in radially compact arrangements and are used in most general purpose applications. The Bearing's dimensions are 165X190X40mm.
The INA equivalent is RNA4830-XL.
| RNA | 48 | 30 |
|---|---|---|
| Single Row Caged Needle Roller Bearing | Dimension Series 48 | 165mm - Bore Size |
Product Information
Technical Data
Inside Diameter (mm):
165
Outside Diameter (mm):
190
Width (mm):
40
Nominal Roller Set Bore Diameter (mm):
165
INA Equivalent:
RNA4830-XL
Dynamic Load Rating (kN):
168
Static Load Rating (kN):
446
Allowable Rotational Speed (r/min):
2500
Max. Operating Temperature:
120°C/248°F
Min. Operating Temperature:
-20°C/-4°F
DescriptionThe RNA4830 is a Standard Duty Open Type, Single Row Machined Needle Roller Bearing with an oil groove and oil hole in the Outer Ring. This Bearing has no Inner Ring, meaning the Needle Rollers are mounted directly onto the shaft. As such, the Bearing has better running accuracy as it isn't affected by assembling an Inner Ring with the shaft. In caged Needle Roller Bearings like this one, the Needles are precisely guided by the Cage to achieve ideal load distribution. These Bearings are designed for high load carrying capacity in radially compact arrangements and are used in most general purpose applications. The Bearing's dimensions are 165X190X40mm. The INA equivalent is RNA4830-XL.
Product InformationBRAND: SKU:rna4830-iko AVAILABILITY:In Stock ✅ WEIGHT:1.75 kg Technical DataInside Diameter (mm):165 Outside Diameter (mm):190 Width (mm):40 Nominal Roller Set Bore Diameter (mm):165 INA Equivalent:RNA4830-XL Dynamic Load Rating (kN):168 Static Load Rating (kN):446 Allowable Rotational Speed (r/min):2500 Max. Operating Temperature:120°C/248°F Min. Operating Temperature:-20°C/-4°F | ||||||
